WB1010 Sumisansui M
It is designed to wet small area with high irrigation performance.
- It irrigates 1.5 meters to one side from the irrigation tube at pressure 0.04 MPa in a windless condition.
- Irrigation performance is highly uniform from the beginning of the tube up to 100 meters.
- Made of special black polyethylene with high durability against sunlight.
- The light weight & compact product isn't only for professional farming but also for hobby gardens.
Use
- All kinds of crops in a young plant stage
- Low to middle height crops such as leaf vegetables and root vegetables
- Turfs such as sport grounds and gardens
Precaution
- Lay down the irrigation tube flatly.
- Operate irrigation under appropriate pressure.
- Install a filtration system to prevent spray holes from clogging.
- Filter recommendation: Over 120 mesh
Product Details
Specification
| Material | Polyethylene |
|---|---|
| Product of Origin | Japan |
| Length (meter/roll) | 100 |
| Packing (rolls/box) | 5 |
| Box size (in cm, LWH) | 25*24.5*31 |
| Box weight (kg) | 9.4 |
| On a pallet (rolls/pallet) | 240 |
|---|---|
| Tube width (in mm, flattened) | 52 |
| Tube diameter (mmφ) | 28 |
| Recommended filtration (#mesh) | 120 |
| Type of fittings | M |
Irrigation performance and water flow rate per pressure
| Operation pressure (MPa) | 0.04 | 0.02 | 0.01 |
|---|---|---|---|
| Coverage: Max. Length (m) | 100 | 100 | 100 |
| Coverage: Width (m) | 3 | 0.18 | 1.2 |
| Recommended tube Interval for placing multiple tubes (m) | 2.4 | 0.1 | 1.0 |
| Average precipitation rate (mm/h) | 9.4 | 111.7 | 11.9 |
| Average flow rate (Litter/min·m) | 0.37 | 0.27 | 0.19 |
| Flow rate at 20m (Litter/min·m) | 0.43 | 0.31 | 0.22 |
| Flow rate at 40m (Litter/min·m) | 0.43 | 0.31 | 0.22 |
| Flow rate at 60m (Litter/min·m) | 0.38 | 0.27 | 0.19 |
| Flow rate at 80m (Litter/min·m) | 0.35 | 0.25 | 0.18 |
| Flow rate at 100m (Litter/min·m) | 0.28 | 0.20 | 0.14 |
