WB1031, WB1030, WB1032 Sumitube Strawberry (WB1031), Tomato (WB1030), Melon (WB1032)
Series of under mulch irrigation tube, which have different hole pitch of 6 cm, 10 cm, 20 cm.
- There's three kinds of tubes prepared depending on spray hole interval.
- All 3 kinds are operated at 0.02 - 0.04 MPa.
- Sumitube Tomato has 10 cm hole interval on a tube, extendable up to 80 meters.
- Sumitube Strawberry has 6 cm hole interval on a tube, extendable up to 60 meters.
- Sumitube Melon has 20 cm hole interval on a tube, extendable up to 100 meters.
- By turning the tube upside down, it wets small area nearby the tube.
- Made of special black polyethylene with high durability against sunlight.
Use
- For fruit and vegetable crops using plastic mulch on a bed
Precaution
- Lay down the irrigation tube flatly.
- Operate irrigation under appropriate pressure.
- Install a filtration system to prevent spray holes from clogging.
- Filter recommendation: Over 80 mesh
Product Details
Specification
| Product | WB1031 Sumitube Strawberry |
WB1030 Sumitube Tomato |
WB1032 Sumitube Melon |
|---|---|---|---|
| Material | Polyethylene | Polyethylene | Polyethylene |
| Product of Origin | Japan | Japan | Japan |
| Length (meter/roll) | 200 | 200 | 200 |
| Packing (rolls/box) | 5 | 5 | 5 |
| Box size (in cm, LWH) | 32.5*32*33 | 32.5*32*33 | 32.5*32*33 |
| Box weight (kg) | 18.1 | 18.1 | 18.1 |
| On a pallet (rolls/pallet) | 240 | 240 | 240 |
| Tube width (in mm, flattened) | 58 | 58 | 58 |
| Tube diameter (mmφ) | 34 | 34 | 34 |
| Recommended filtration (#mesh) | 80 | 80 | 80 |
| Type of fittings | ST | ST | ST |
Irrigation performance and water flow rate per pressure
| Product | WB1031 Sumitube Strawberry |
WB1030 Sumitube Tomato |
WB1032 Sumitube Melon |
|||
|---|---|---|---|---|---|---|
| Operation pressure (MPa) | 0.04 | 0.02 | 0.04 | 0.02 | 0.04 | 0.02 |
| Coverage: Max. Length (m) | 60 | 60 | 80 | 80 | 100 | 100 |
| Average flow rate (Litter/min·m) | 1.29 | 3.91 | 0.78 | 0.55 | 0.61 | 0.43 |
| Flow rate at 20m (Litter/min·m) | 1.32 | 0.93 | 0.80 | 0.56 | 0.63 | 0.44 |
| Flow rate at 40m (Litter/min·m) | 1.30 | 0.92 | 0.79 | 0.56 | 0.62 | 0.44 |
| Flow rate at 60m (Litter/min·m) | 1.24 | 9.88 | 0.78 | 0.55 | 0.62 | 0.43 |
| Flow rate at 80m (Litter/min·m) | - | - | 0.76 | 0.53 | 0.60 | 0.43 |
| Flow rate at 100m (Litter/min·m) | - | - | - | - | 0.59 | 0.41 |
