In Open field
WB8029 Sumisansui MarkⅡ
The MarkⅡ with spray angle of “Over 60 degrees” has wide adaptability to crops regardless of plant size.
- “Over 60 degrees” spray angle is usable for wind range of crops.
- It irrigates 2 meters to both sides from the irrigation tube at 0.08 MPa in a windless condition.
- Irrigation performance is highly uniform from the beginning of the tube up to 100 meters.
- The light weight & compact product isn't only for professional farming but also for hobby gardens.
- Made of special black polyethylene with high durability against sunlight.
Use
- All kinds of open field crops from seeding to young plant stage
- Tall plants such as orchards
- Turfs such as sport grounds and gardens
Precaution
- Lay down the irrigation tube flatly.
- Operate irrigation under appropriate pressure.
- Install a filtration system to prevent spray holes from clogging.
- Filter recommendation: Over 80 mesh
Product Details
Specification
| Material | Polyethylene |
|---|---|
| Product of Origin | Japan |
| Length (meter/roll) | 100 |
| Packing (rolls/box) | 5 |
| Box size (in cm, LWH) | 27*26.5*30.5 |
| Box weight (kg) | 12.0 |
| On a pallet (rolls/pallet) | 240 |
|---|---|
| Tube width (in mm, flattened) | 50 |
| Tube diameter (mmφ) | 28 |
| Recommended filtration (#mesh) | 80 |
| Type of fittings | M |
Irrigation performance and water flow rate per pressure
| Operation pressure (MPa) | 0.08 | 0.02 |
|---|---|---|
| Coverage: Max. Length (m) | 100 | 100 |
| Coverage: Width (m) | 4 | 2 |
| Recommended tube Interval for placing multiple tubes (m) | 3.2 | 1.6 |
| Average precipitation rate (mm/h) | 5.1 | 4.9 |
| Average flow rate (Litter/min·m) | 0.45 | 0.22 |
| Flow rate at 20m (Litter/min·m) | 0.48 | 0.23 |
| Flow rate at 40m (Litter/min·m) | 0.46 | 0.23 |
| Flow rate at 60m (Litter/min·m) | 0.45 | 0.22 |
| Flow rate at 80m (Litter/min·m) | 0.43 | 0.21 |
| Flow rate at 100m (Litter/min·m) | 0.41 | 0.21 |
